NVidia Anti-Aliasing Guide (updated)

Are you using Normal or Interlaced rendering? Interlaced seems to be fancy image reconstitution - lowers my GPU usage by a ton while looking a lot more aliased. I couldn't see any aliasing at all with TAA on Normal rendering mode (though visible with close scrutiny), but shimmering is all around with Interlaced.

SMAA is outright broken for me. No effect, huge FPS drop. Probably bugged. As for using it with TAA, the more logical thing would be for them to just mean T2x/4x SMAA - seeing as their engine obviously already generates the data for it.



I'm using normal rendering. Interlaced mode looks awful.

There is still quite a bit of aliasing left with TAA. Specifically high contrast edges and small specular highlights on objects.

It's a huge improvement over no AA however and a bigger improvement over 4xOGSSAA even.
In the screenshot I posted before.
http://u.cubeupload.com/MrBonk/HBAOghosting.jpg
This is cropped from an 1800p render. You can see the thin specular detail on the picture frame to the upper left are not properly resolved.

Using DSRTool to play the game at 4k on my 900p monitor, the results are quite a bit better than with 2.25x DSR+4xSSAA in game.

Also: If you dont' have a ton of VRAM, turn off the Shadow Cache. This causes immense stuttering and performance issues for me.

I found as well, if we could get a clone of Adobe's exact code for Photoshop's "Sharpen more" filter as a Reshade shader. Then image sharpness will be almost 100% the same as without TAA
http://screenshotcomparison.com/comparison/194478



Dear all,

I am looking for the "antialliasing Compatibility"code for my game ASSETTO CORSA working in DX11.

Can you help me because i found nothing for this game.

many thanks in advance.

ps: sorry for my english



There are no codes for DX11. The driver only supports DX9 and a few DX10 titles.



thanks for you quick answer.


in Nvidia inspector profile, is it not possible to reduce the alliasing of this game?



Assetto Corsa has good ingame MSAA, which can be enhanced with driver SGSSAA:
https://forums.geforce.com/default/topic/540947/sli/assetto-corsa-sli-profile/

Combine that with a high native resolution and/or DSR, and image quality is very good.
All of this information is already in my master list spreadsheet.



Adventure Time Finn and Jake Investigations

This game runs on Vicious Engine 2. As a big AT fan, I was disappointed to hear this. But I hoped the PC version would be decent this time.
Nope.

As per usual with VE games it suffers

• OSD Software doesn't work
• 30FPS Lock, with unstable frame pacing/Vsync. Force 30FPS lock and 1/2 Sync from outside the game.
• No video options
• Ultra low quality SSAO that contributes a lot of temporal issues
• Crashes at any resolution bigger than 2048x1152. A new regression from the last game running on this engine. Pac-Man and The Ghostly Adventures.
  The game detects any arbitrary resolution but crashes as soon as you select it. If you do this, then you need to edit the registry settings for the game to a lower resolution. (See PCGWiki)

It also has built in PPAA this time around, but it's mediocre as usual. And also interferes with SGSSAA a little bit.
Making the visuals softer while decreasing edge quality a small amount.


AA fix should be used as it increases quality.
0x000012C1 - SGSSAA
0x004012C1 - SGSSAA if you use ReShade
0x000112C1 - Higher quality SGSSAA but softer visuals. Though it causes some minor issues with specular shading of only specific objects. It's not a terribly bigger issue. Edge quality is much better in general. (It;s the 1 that does it, and can be used with the ReShade flag as well)

The image can be sharpened through SweetFX, but if you want to use Reshade, the Depth bit needs to be set. And for whatever reason, this interacts with SGSSAA being forced, so it tries to apply AA to ReShade and it's effects as well. Which causes the performance to decrease massively.
At 1080p with 8xSGSSAA my 980 is hitting 90-100% usage and has frame drops.

So that's not very useful. But an option if you have a 1080 maybe.


No AA Title Screen | Menu | House | Outside house
8xSGSSAA 12C1 Title Screen | Menu | House | Outside house
8xSGSSAA 112C1 Title Screen | Menu | House | Outside house
8xSGSSAA 4112C1 Reshade Sharpening Title Screen | Menu | House | Outside house
8xSGSSAA 112C1 SweetFX sharpening Title Screen | Menu | House | Outside house


Here's the Preset for ReShade https://www.mediafire.com/?6gpd4u5ii0ux62m
Here's the SweetFX preset https://www.mediafire.com/?6gpd4u5ii0ux62m

It's a shame there is no video options and the game doesn't support more than 1080p basically.



Some AA Flags for assassin`s creed rogue ?



It's a DX11 game. So it's impossible. If it has the TXAA options ACIII had, then you can enhance that with SGSSAA



Dragon Quest Heroes bits anyone? This game has some NASTY aliasing issues.
Still using reshade for it..



DX11 only game, and developer/publisher is incompetent. If it supported greater than 1080p, then you could do something.

If you could figure out at what memory address the game stores it's resolution information, you might be able to hack it with hex editing or something else. (Someone unlocked MGRising's resolution this way. As well as Akiba's Trip. I tried to do the same for Raiden III and IV. But no dice)



Would you mind explaining how to do this? I've tried with multiple TXAA games and never had it work.



If you talk about DQH - its NOT dx11 game. :3eyes:
Somehow, i also thought it was, but system reqs says otherwise. Also reshade don't work in dx10/11 mode, only in dx9



Really? Last I heard it was DX11. Would you mind posting a screenshot with an OSD?

Turn on 4xTXAA (Or 2x and use the application settings)
Then set NPI like such


Worked for me in ACIII, big performance hit. But noticeable difference. Just depends on the game.



Oops, OSD shows DX11 :bang: This game is ****ed.
I wonder why Reshade works only with dx9 dll on this game..



HUGE thanks for this! Doing exactly what you showed made an absolutely massive difference in Splinter Cell : Blacklist! I've owned the game since release, but haven't played it much because none of the in game AA settings would catch the shimmering and transparency aliasing. A couple of days ago I finally got to the 3rd campaign mission while using Ultra settings @ 1620p with the in game MSAA as high as it would go. Still didn't look all that great.

Now I'm playing at Ultra settings @ 1080p with the in game 4xTXAA and your NPI settings. It looks MILES better in every way. Thanks for showing me how to do this. I do have another question. Can you do this sort of thing with games that use TAA, like Fallout 4, or is it just for games with the nVidia specific TXAA?



Yup, it is a shame. Your only option is to try hex editing the game exe to find the hex equivalent of 1920x1080 and replace it with another resolution and see if it works.

1920x1080 in hex in the exe would be

8007 0000 3804 (If I remember everything correctly that is, there might be two empty bytes between 8007 0000 0000 3804)

The number you'd replace it with would have to converted to hex
http://www.binaryhexconverter.com/decimal-to-hex-converter
Add a 0 to the first digit and then byte swap the number.

1920=0780 >8007

You might try looking without byte swapping too. You never know. Something to do with Endianess? (Not a programmer)

If you knew what to look for, I wonder if Cheat Engine would be of any help as well. I'd really like to find a way to hack higher resolutions easily into games that are old or ported poorly. (Like most Tecmo Koei games )

It works with every game that has Nvidia TXAA only (Because it's based on MSAA) and the quality will greatly vary depending on the game's implementation of TXAA and MSAA.



DSR is possible, but you should use Cheat Engine to activate it.

• Setup DSR resolution on desktop
• Run game and stay in main menu
• Alt+Tab game
• Uncheck "Writable" and search two grouped values:
  4:640 4:800 4:1024 4:1280 4:1360 4:1600 4:1920
  and
  4:360 4:450 4:576 4:720 4:765 4:900 4:1080

• Change any two resolution values to DSR. But not current one that game uses.
  For example, change 1280 and 720 to 3840 and 2160

• Alt+Tab back to game and select 1280x720 resolution in graphics settings

Here's resolution table:

But game exe protected via steam stub, and it simply won't start after modification.



Well that's frustrating. Not only did they do a bad job supporting basic PC features, they locked you out of the only way to directly fix it permanently.

It's not like it's a competitive online game jeez.


Thank you for stepping in by the way. Do you have any tips that could help with this with other games?
Like how you can spot where the resolution table is in the .exe addresses?
Would Cheat Engine see the same addresses in real time as the game is running?
You would have to have cheat engine running every time the game runs?

Do you mind if I use that post as a reference for the game in the OP Document?
I like to put games that any kind of alternate solution available if they can't be forced.
It might be useful for the PCGamingWiki.com page as well
http://pcgamingwiki.com/wiki/Dragon_Quest_Heroes

Makes me want to revisit Raiden III and IV to see if I can use this method to fix anything and whether I did something wrong when hex-editing.

Here's a comparison using your images as well. To KainXVIII, if you use SMAA/FXAA on top before downsampling it would also help clean up the remaining rough edges.
http://screenshotcomparison.com/comparison/196387



Thanks for all answers, i will try it (foliage looks so much better!)
