HD4870 Fan Control

eXme · **Memory**: DDR2-800Mhz 4GB 4-4-4-15

Hi, maybe someone know any good Fan soft for HD4870 Powercolor. My GPU temp is always over 80 °C (not overlocked) i using GA-EP45-DS3R mainboard. Thanks for help Gurus!

EDIT:

First of all thank to Gurus! =)

So I figure out that the best temp for idling and for small games (not so noisyyyyyy) is 45% for games like Crysis 60% is enough! So youll have 55-65 °C temperature as I read in ATI manuals this temp is okey.

eXme · **Memory**: DDR2-800Mhz 4GB 4-4-4-15

Check my FAN speed its insane! I want at least 50% but dunno how to set up =( Help!

ReDi · 07-29-2008, 10:31 | posts: 111 | Location: The Netherlands

You haven't heard of the fan fix I guess?

http://www.nvnews.net/vbulletin/show....php?p=1704215

evilfury · 07-29-2008, 10:33 | posts: 521 | Location: Slovenia

How come you have a core clock set at 500mhz? Isnt the default for 4870 750mhz?

ReDi · *Last edited by ReDi; 07-30-2008 at 08:08.*

Here's what I found on my system, temperature vs fan speed:

So a fan speed of 30-35% is sufficient to get the idle temperature to an acceptable level. For gaming I recommend 45-50%, but you'llhave to experiment. Just make separate profiles for the fan speeds you need and try them out.

YWAGMOTH · 07-29-2008, 10:34 | posts: 621

here you go dude,if you serched the forum you will find losts of theads like this,but here you go how to create the profiles

http://forums.guru3d.com/showthread.php?t=265745&page=4

ReDi · 07-29-2008, 10:36 | posts: 111 | Location: The Netherlands

Quote:

Originally Posted by evilfury

How come you have a core clock set at 500mhz? Isnt the default for 4870 750mhz?

I also have 500Mhz reported in some tools, others show 750Mhz and some show both. Not sure what it means, but I'm sure my card works fine

Maybe it's some throttling, or 2D vs 3D?

ReDi · 07-29-2008, 10:40 | posts: 111 | Location: The Netherlands

Note: when searching for the .xml file, make sure hidden files and folders are shown in your file manager/explorer.

eXme · **Memory**: DDR2-800Mhz 4GB 4-4-4-15

Thank you everyone! Ill try analyze that links!

eXme · **Memory**: DDR2-800Mhz 4GB 4-4-4-15

A HUGE THANKS! Working fine, but temperature are still so high I put it to 100% and maximum temperature i have by idling is 55%.

Cant find any posts about HD4870 with water cooling systems. Any ideas maybe some of your friends trying to cool it with water?

eXme · **Memory**: DDR2-800Mhz 4GB 4-4-4-15

With GPU Clock 500Mhz and Memory Clock 810Mhz with 100% Fan I cooled it too 50 °C. That means that my problem is 100% solved!

Thank you Gurus!

ReDi · 07-29-2008, 11:49 | posts: 111 | Location: The Netherlands

Quote:

Originally Posted by eXme

With GPU Clock 500Mhz and Memory Clock 810Mhz with 100% Fan I cooled it too 50 °C. That means that my problem is 100% solved!

Thank you Gurus!

Are those idle temperatures? It seems that needing 100% fan speed to get those temperatures is a bit too much. Sounds like air flow in your case is not very good.

philheckler · 07-29-2008, 12:10 | posts: 775 | Location: S.WALES UK

yes still way to high for a fan speed of 100% - ive got mine running at 35 % idling at 45c / 60 c at full load and its overclocked to the max ccc limit - btw when this card is idling the clocks automatically drop to 500 / 900 so don't worry about that..

Bold Eagle · **Memory**: 4Gb Crucial 4-4-4-12

Have to agree I'm folding with 99% GPU load@50% Fan and 62C, ambient temp here is about 14C. You may want to consider removing the HS and refreshing the TIM with a quality product.

eXme · **Memory**: DDR2-800Mhz 4GB 4-4-4-15

My PC is running more then 2 days without rest, and there is 42 °C outside and my box is closed. And yes its idle temperature. I set it to 45% and i have around 55-60 °C when i play it goes 65-70 °C by Legend - Hand of God game. Havent tryed other games..

tech}{nine · 07-30-2008, 04:54 | posts: 53 | Location: Canada

i cant find the xml file
i made a profile and cant find it.

DSK · 07-30-2008, 05:56 | posts: 17,984 | Location: Coldwells,UK

the gpu jumps from 500mhz to 750mhz when load is put on it

and i only need 30% fan speed to get a nice 50c idle and 70c load

just type in the run bar ...dont try and find it by looking in folders its just impossible lol

C:\Users\kylzer\AppData\Local\ATI\ACE just replace kylzer with your windows username

ReDi · 07-30-2008, 08:10 | posts: 111 | Location: The Netherlands

Quote:

Originally Posted by tech}{nine

i cant find the xml file
i made a profile and cant find it.

Quote:

Originally Posted by kylzer

just type in the run bar ...dont try and find it by looking in folders its just impossible lol

C:\Users\kylzer\AppData\Local\ATI\ACE just replace kylzer with your windows username

The folder is hidden by default. Go to Tools/Folder Options/View in explorer and check the 'Show Hidden Files and Folders' option. That should do the trick.

Postalisback · 07-30-2008, 08:14 | posts: 3,569 | Location: pualuiɟ

You don't need to do that btw, if you just type it in the white bar near the top of the window (long white bar/space) and press Enter it does the same thing without having to change the options...

ReDi · 07-30-2008, 08:21 | posts: 111 | Location: The Netherlands

Quote:

Originally Posted by Postalisback

You don't need to do that btw, if you just type it in the white bar near the top of the window (long white bar/space) and press Enter it does the same thing without having to change the options...

That's a good tip, thanks. Though personally I usually make less mistakes with clicking buttons than with typing a 30+ character folder path

Postalisback · 07-30-2008, 09:10 | posts: 3,569 | Location: pualuiɟ

Okay fair enough, I just never use the switches now, I just copy and paste

nOv1c3 · 07-30-2008, 11:46 | posts: 1,051 | Location: Dallas texas

Quote:

Originally Posted by tech}{nine

i cant find the xml file
i made a profile and cant find it.

Mine was hidding here lol I,m using winXP sp2

C:\Documents and Settings\nOv1c3\Local Settings\Application Data\ATI\ACE\Profiles
