*-=The Guru of 3D rig gallery rev.2 Part 9=-*

[signex]

Originally Posted by hallryu

I'm stunned by the performance of the H100 with 4 NF-F12's. My PC is so quiet compared to its older incarnation.

At full speed the only issue is slight 'hum' from the fans on the H100 radiator. However, at 1200rpm its gone and my PC is whisper quiet.

In normal operations I've noticed a slight increase in idle temps of 1 or 2 degrees. Load temps in Prime are sensational at between 52 and 58C. Give or take a degree or 2 depending on ambient.

I had the H80 months ago, stock fans made horrid sounds lol.

[BLEH!]

Never actually posted any photos of this yet, so here it is:



Before adding 2nd fan back onto Noctua.



With 2nd fan on Noctua.



Visual and audio monitors. Forgive the crap on the desk. I'm a messy git.



Audio rack. Usually have a Line 6 Pod X3 Pro sat on top there but it's currently back with them for repairs.

Specs:

Coolermaster HAF-X w/all fans, top 2 LED ones.
Enermax Revo 1500W PSU
ASUS P6T7 WS Supercomputer motherboard
Intel Xeon W3680 (think 980X) overclocked to 4.53 GHz @ 1.38 V.
Noctua NH-D14 Cooler
6 x 4 GB Corsair Dominator GT RAM running at 1600 MHz @ CAS 9-9-9-24 (I'm gunna try and reduce the timings soon, any faster and it doesn't run properly).
2 x MSI Radeon HD7970s overclocked to 1040 MHz on the core and 1575 MHz on the VRAM, stock voltage.
LG DVD-RW Drive
5 x 1 TB HDDs, various makes, boot drive 7200 rpm WD.

Screen: Dell U2711
Keyboard: Razor Lycosa (piece of crap, getting something better soon).
Mouse: Razor Death Adder (love this thing, fits my hand great.
Soundcard: Focusrite Saffire Pro 40 (for recording)
Speakers: KRK Rokit 5's

Think that's about it

[RoadKillNL]

Thought id show mine now i got a proper camera (Images have been resized)







If you wonder why the 580 isn't in the first PCI-E Slot. Basicly i'm trying to create more breathing room for all components.

[Gripen90]

^^ So nice and clean !


Old CM 690. No super cable management options, still I love the case for it's superb airflow capabilities. I'm not changing this old 2009 case before it rusts to pieces

[Matt26LFC]

Nice builds guys, got some more bits and pieces coming 2morrow and next week, nothing fancy, but hopefully my build will be more or less complete and I can throw up some shots.

[airbud7]

[BlooHook]

Out with the old...







...in with the new!

[Sir Galahad]

My 2 low profile builds:



LAN party anybody?


Yeah I like the all black look.

[Brendruis]

Nice build in the GT case. Can you come out with the sleeved cables for the PCI-E power on the same grommet as the ATX power? Just my 2cents I think that would look "cleaner"

But I shouldn't speak probably my 600T still needs some sleeve loving

[Mineria]

I don't have a good camera, but I guess these will do anyway.

Here is my current setup in a Haf X, with black sleeved cables, except for the one going to the audio card, didn't get to fix that one yet.

[FULMTL]

Yeah, new mouse - SteelSeries Sensei

Still messing with the colors. Right now it's magenta scroll wheel and dot, and teal logo.


The LCD on the back :3

[MikeMK]

Look what arrived at my door today!









Will be installing over the next day or two!

[Gene5is]

Hi!

Been reading this forum for so long but decided to start posting just about now =P

this is my humble work, took this photos at the beggining of this year!.. feel free to post suggestions! they are appreciated!









ive fixed some of the cables positions and overall management but been too lazy to upload new pics!..

[Jaberwocki87]

New rig

[ultraex2003]

[signex]

I'm updating my rig next week with some sleeved cables (thank god for premade sleeved cables) but only could find white ones.

And with red lights.

Will it look good white sleeved cables with red lights in case?

I hope i get my own money back soon so i can build an high end rig again like i had before.

edit: wow they even have sleeved frontpanel cables! wich i ordered

[mikeysg]

Here are mine - Main rig in profile


2nd rig - AMD FX8120 + CM Hyper 412Slim (with Corsair SP120 fan) + Asus Crosshair V Formula + 8GB OCZ DDR3 1600mhz RAM + MSI GTX670 OC Ed + GTX460 768MB (PhysX) + Corsair 120GB ForceGT SSD + 1TB WDC Black + 1.5TB WDC Green + Seasonic SS-850AT

3rd/HTPC Rig -
C2Q X9650 + TRUE 120 Black + Asus Maximus II Formula + 4GB KHX DDR2 PC8500 + Sapphire HD6970 2GB + Corsair 120GB Force 3 SSD + 2x 1TB WDC Black + SilverStone OP1000

The last pic was when I had the FX installed in it, swapped out the FX to the Tt Commander MS-II and installed the X9650 build into the red LED Sharkoon case.

[meds]

[MybadOmen]

My NZXT Switch 810 modded to the Mass Effect 3 Theme. Enjoy !































MybadOmen

[MikeMK]

A quick shot of my new 7970's installed on air... I'll post better pics once they are on water in a month or so!

[BlackZero]

@BlooHook + mikeysg

Those monsters look awesome.

After having used a steel armor+ weighing 40kg when kitted out with multiple radiators I can't imagine going back to a simpler designed and lighter case. It would just feel too delicate and perhaps 'too clean' even. I'm generally all for simple elegance but in this case (no pun intended) seems like I've developed a bit of a thing for heavy quirky cases.

I find it interesting that certain people like to hit out at these cases having never tried one or even considered what it is that makes them stand out to many. But then I've had the case fall on me a couple of times during loop maintenance so some of the pros can easily also be cons.

To each their own.

[Sash]

I've completed my new rig, FINALLY!

[Gripen90]

Cleaned up as much as possible after upgrading to X79 platform and getting a new SSD for OS. Next time I upgrade I might have to get a Coolermaster CM690 Advanced II nVidia Edition since it has better cable management options.

[_REAPER_]

Here are a few updates to my RIG

[nyrmetros]

This is my new Haf X build. Please let me know what I can do to clean things up or some tricks that I can do.
